Open Frame 6U 50HP Chassis

An open-frame solution for the open-minded engineer. With moveable rear profiles (up to 2.5mm,) 3U and 6U backplane compatibility options, air or conduction cooling options and the ease of fast and simple backplane interchangeability for fluid transition between VITA and PICMG bus architectures, the Hartmann Open Frame Chassis solution is the tool for customers who need versatility, accessibility and longevity.

An adjustable locking grab handle, tilt or flush-sitting feet, durable open frame supports and a light-weight 600W ATX power supply allow the chassis to be moved from the lab to the developer’s workstation to the field for demonstration with ease.

Note: Open Frame Chassis are optioned with or without a backplane. Please ask your Hartmann sales professional which of our backplane solutions is best for you.

Additional Information

Mounting

Desktop

Backplane

6U up to 12 slots (PCI, Serial, PXI, VME, VPX)

Fan Tray

Internal with adjustable fan speed

No. of Fans

2 front side fans 224CFM, 64dB(A), 3A, 3 rear side fans 80x80x25mm, 39CFM, 34dB(A), 0.23A

Airflow

Bottom to top

Power Supply Type

600W ATX

Power Input

90 – 264Vac

No. of Supplies

1

Output Voltages

12V/45A, 3.3V/25A, 5V/25A, -12V/0.8A

Power Supply Connector

Rear side with switch

Chassis Height

450 mm

Chassis Width

50 HP

Chassis Depth

302 mm

IEEE

1101.1 and 1101.10/11

IEC

60297-3-101, -102, -103

Military Shipboard

MIL-STD-810F: 514.5C-15 (vibration)

Military Highway

MIL-STD-810F: 514.5 C-1 (vibration), 515.5-10 (shock)

Railway

EN 50155-EN 1373 class 1 B, rolling stock (shock/vibration)
